Laser Glass Sandblasting Machine

Name: Laser Glass Sandblasting Machine
Brand: Enoble

V3, Hottoo and Uttoo Series for Glass Frosting, Coating Removal and Drilling

The Enoble Laser Glass Sandblasting Machine is available in three series for different production scales: V3 for large-format architectural and decorative glass, Hottoo for regular decorative glass production, and Uttoo for compact workshop use.

Each series supports digital glass surface processing from AutoCAD and CorelDRAW files, with file formats including DXF, AI, SML and JPG. Available process functions include frosting / sandblasting, coating removal and drilling.

Series	Best Fit	Catalog Processing Range	Power Range
V3 Series	Architectural and large-format decorative glass	1225 x 2500 mm to 3000 x 6000 mm	8.5-14.5 kW
Hottoo Series	Regular decorative glass, logos and privacy glass	1200 x 2500 mm to 1500 x 3000 mm	8.5 kW
Uttoo Series	Compact workshops and small-to-medium glass	1000 x 1000 mm to 1300 x 2500 mm	7.0 kW

Core Performance

The technical data below is organized by series so buyers can compare processing size, machine footprint, power and weight before requesting a configuration.

Parameter	Specification
Laser Power	120 / 180 / 200 W
Software	AutoCAD, CorelDRAW
Formats	DXF, AI, SML, JPG
Functions	Frosting / Sandblasting, Coating Removal, Drilling

V3 Series Model Parameters

Model	Max. Processing Size	Footprint	Power	Weight
EN-L1225-V3	1225 x 2500 mm	5200 x 2400 mm	8.5 kW	2800 kg
EN-L1525-V3	1500 x 2500 mm	5200 x 2700 mm	8.5 kW	3000 kg
EN-L1530-V3	1500 x 3000 mm	5700 x 2700 mm	8.5 kW	3200 kg
EN-L2030-V3	2000 x 3000 mm	5700 x 3200 mm	8.5 kW	3600 kg
EN-L2436-V3	2400 x 3600 mm	6300 x 3600 mm	14.5 kW	3900 kg
EN-L3060-V3	3000 x 6000 mm	8700 x 4200 mm	14.5 kW	5400 kg

Hottoo Series Model Parameters

Model	Max. Processing Size	Footprint	Power	Weight
EN-L1225-H	1200 x 2500 mm	4500 x 3300 mm	8.5 kW	2400 kg
EN-L1525-H	1500 x 2500 mm	4600 x 3300 mm	8.5 kW	2500 kg
EN-L1530-H	1500 x 3000 mm	5200 x 3300 mm	8.5 kW	2700 kg

Uttoo Series Model Parameters

Model	Max. Processing Size	Footprint	Power	Weight
EN-L1010-U	1000 x 1000 mm	2000 x 1700 mm	7.0 kW	1200 kg
EN-L1320-U	1300 x 2000 mm	4000 x 2700 mm	7.0 kW	1500 kg
EN-L1325-U	1300 x 2500 mm	4000 x 3500 mm	7.0 kW	2000 kg

Key Features

Each series is built for a different production environment, so the key features are separated by series for easier comparison.

V3 Series	Hottoo Series	Uttoo Series
FEA-based deep structural optimization. Fiber laser with autonomous parameter optimization. High-capacity oversized servo motors with strong power. Gantry: Y-axis dual rail + main beam triple rail. Tracking suction + pulse-jet dust collector. Dual temperature chiller for stable thermal control.	Precision welded steel structure – sturdy and durable. Precision CNC machining meeting accuracy standards. Thickened aluminium material – stable and durable. Annealing relieves stress and enhances rigidity. Precision assembly with attention to every detail. Gantry: Y-axis vertical double rails + triple-rail main beam.	High-strength steel welding – stable and aesthetic. CNC integrated machining for high precision. Thick aluminium profiles – sturdy and stable. Annealing relieves stress, enhances airframe durability. Precision in assembly, craftsmanship at heart. Gantry: Y-axis dual rail + main beam triple rail.

Machine in Action

Watch Laser Glass Processing Videos

See selected Enoble Glass videos showing laser glass etching, decorative pattern processing, glass drilling and flexible surface work. These videos help buyers understand practical applications before choosing V3, Hottoo or Uttoo configurations.

Photo Etching

Photo Etching on Glass

Shows laser photo etching directly on glass for decorative and customized surface processing.

Watch Short

Patterns

Decorative Pattern Processing

Shows customized shapes and decorative patterns made with laser glass processing.

Watch Short

Drilling

Clean Glass Drilling Demo

Demonstrates clean and accurate glass drilling with laser processing.

Watch Short

Decorative Glass

Flexible Decorative Glass Processing

Shows how laser technology supports flexible decorative glass surface processing.

Watch Short

Applications

Applications are grouped by series to help buyers match the laser glass sandblasting machine to the required glass type, order volume and workshop space.

Series	Applications	Selection Guidance
V3 Series	Architectural Decorative Glass; Mirror & Furniture Glass; Privacy Glass; Signage & Branding	Choose V3 when the required glass size or project mix is closer to architectural and large-format decorative work.
Hottoo Series	Decorative Glass Patterns; Glass Logos; Privacy Glass; Promotional & Signage Glass	Choose Hottoo for regular factory production of decorative patterns, logos and privacy glass.
Uttoo Series	Compact Workshop; Small to Medium Glass; Custom Pattern Glass; Mirror Industry	Choose Uttoo when floor space, compact installation and small-to-medium custom orders are the main priorities.

Long-Term Value

For quotation and configuration, the most useful information is the target glass size, required process type, pattern complexity, expected output and available floor space. These inputs help match the project to V3, Hottoo or Uttoo without over-specifying the machine.

Which series is best for large-format architectural glass? V3 is the catalog series for architectural decorative glass and larger processing sizes, up to 3000 x 6000 mm.	Which series is best for routine decorative production? Hottoo is positioned for decorative glass patterns, glass logos, privacy glass and promotional or signage glass.
Which series fits a compact workshop? Uttoo is the compact option for small-to-medium glass, custom pattern glass and mirror industry applications.	What file workflow is listed in the catalog? The catalog lists AutoCAD and CorelDRAW software support, with DXF, AI, SML and JPG formats.
